11_A assignament

Request

Discover a new important stochastic process by yourself! Consider the general scheme we have used so far to simulate some stochastic processes (such as the relative frequency of success in a sequence of trials, the sample mean and the random walk) and now add this new process to our simulator. Same scheme as previous program (random walk), except changing the way to compute the values of the paths at each time. Starting from value 0 at time 0, for each of m paths, at each new time compute N(i) = N(i-1) + Random step(i), for i = 1, …, n, where Random step(i) is now a Bernoulli random variable with success probability equal to λ * (1/n) (where λ is a user parameter, eg. 50, 100, …). At time n (last time) and one (or more) other chosen inner time 1<j<n (j is a program parameter) create and represent with histogram the distribution of N(i). Represent also the distributions of the following quantities (and any other quantity that you think of interest):

Distance (time elapsed) of individual jumps from the origin
Distance (time elapsed) between consecutive jumps (“holding times”)

My Solution

[Code in C#]https://github.com/yuky2020/Statistics-Pratical-LABS/tree/main/Assignment10/C%23/BernulliGraphics)

The part in disegna Grafici in witch i call the various usefull function

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12


      {
                distrubution = new BernulliPathfinder(n, m, lambda);

                disegnaPaths(fromPathstoViewport(distrubution.Get_paths(), viewPort));

                disegnaHistogramma(viewPort, getDistribution(distrubution.Get_paths(), m / SCALE, j), n, j);
                disegnaHistogramma(viewPort, getDistribution(distrubution.Get_paths(), m / SCALE, n), n, n);
                //disegno le distanze
                disegnaDistanze(viewPort, individualJumpFromOriginD(distrubution.Get_paths()), 0, "Single jump distace ");
                disegnaDistanze(viewPort, doublejumpD(distrubution.Get_paths()), 80, "Double jump distance");

            }

the class for writing the histogram and for get the distribution are the same as the precedent hw so i will skip it,but bernulli pathfinder now work with lamba insted of p

Bernoulli pathfinder class

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54


      public class BernulliPathfinder: Pathfinder
    {


        int m;      //number of paths
        int n;      //number of points
        double p;   //probability
        public List<Strade> paths = new List<Strade>();
        private Random R;

        public BernulliPathfinder(int n, int m, double p)
        {
            this.m = m;
            this.n = n;
            this.p = p;

            this.R = new Random();

            for (int i=0; i < m; i++)
            {
                paths.Add(new Strade(createBernulliList()));
            }



        }

        private int bernoulli_Result(double p,int n)
        {
           double random_outcome = R.NextDouble();

            if (random_outcome <= p/n) return 1;
            else return 0;
        }

        private List<double> createBernulliList()
        {
            List<double> bernoulli = new List<double>();

            for (int i = 0; i < n; i++)
            {
                bernoulli.Add(bernoulli_Result(p, n));
            }

            return bernoulli;
        }
       public List<Strade> Get_paths()
        {
            return this.paths;
        }



    }

Disegna Distanze method

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31


     private void disegnaDistanze(Rectangle viewPort, Dictionary<int, int> intervals, int offset, String text)
        {
            int i = 0;
            SolidBrush semiTransBrush = new SolidBrush(Color.FromArgb(128, 0, 0, 0));

            foreach (var v in intervals)
            {
                int x, y;
                int width, height;
                // in this case on the fly trasformation is way faster
                x = (int)(this.viewPort.Left + 20 * i);
                y = (int)(viewPort.Top + viewPort.Height + offset);


                width = v.Value;
                height = viewPort.Height / intervals.Count;

                Rectangle rectangle = new Rectangle(x, y, width, height);

                g2.DrawRectangle(Pens.Black, rectangle);
                g2.FillRectangle(semiTransBrush, rectangle);

                g2.FillRectangle(Brushes.Violet, rectangle);
                g2.DrawString(v.Key.ToString(), new Font("Calibri", 10.0f,
                                 FontStyle.Regular, GraphicsUnit.Pixel), semiTransBrush, new Point(x, y));
                i++;
            }
            g2.DrawString(text, new Font("Calibri", 13.0f,
                               FontStyle.Italic, GraphicsUnit.Pixel), semiTransBrush, new Point(this.viewPort.Left - 140, (viewPort.Top + viewPort.Height + offset)));

        }

Individual jump

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26


     private Dictionary<int, int> individualJumpFromOriginD(List<Strade> strades)
        {
            Dictionary<int, int> dbj = new Dictionary<int, int>();
            int i = 0;
            int tmp = 1;
            Boolean trov = false;
            foreach (Strade s in strades)
            {
                i = 0;
                tmp = 1;
                trov = false;
                while (!trov && (i < s.getPath().Count() - 2))
                {
                    if (s.getPath()[i].Y != s.getPath()[i + 1].Y) trov = true;
                    i++;
                }
                i++;
                if (dbj.TryGetValue(i, out tmp))
                {
                    dbj.Remove(i);
                    dbj.Add(i, tmp + 1);
                }
                else dbj.Add(i, tmp);
            }
            return dbj;
        }

Double jump

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26


    private Dictionary<int, int> doublejumpD(List<Strade> strades)
        {
            Dictionary<int, int> dbj = new Dictionary<int, int>();
            int i = 0;
            int tmp = 1;
            Boolean trov = false;
            foreach (Strade s in strades)
            {
                i = 0;
                tmp = 1;
                trov = false;
                while (!trov && (i < s.getPath().Count() - 2))
                {
                    if (s.getPath()[i].Y != s.getPath()[i + 1].Y && s.getPath()[i + 1].Y != s.getPath()[i + 2].Y) trov = true;
                    i++;
                }
                i = i + 1;
                if (dbj.TryGetValue(i, out tmp))
                {
                    dbj.Remove(i);
                    dbj.Add(i, tmp + 1);
                }
                else dbj.Add(i, tmp);
            }
            return dbj;
        }
