12_A assignament

Request

Discover one of the most important stochastic process by yourself !

Consider the general scheme we have used so far to simulate stochastic processes (such as the relative frequency of success in a sequence of trials, the sample mean, the random walk, the Poisson point process, etc.) and now add this new process to our simulator.

Starting from value 0 at time 0, for each of m paths, at each new time compute P(t) = P(t-1) + Random step(t), for t = 1, …, n, where the Random step(t) is now:

σ * sqrt(1/n) * Z(t),

where Z(t) is a N(0,1) random variable (the “diffusion” σ is a user parameter, to scale the process dispersion).

At time n (last time) and one (or more) other chosen inner time 1<j<n (j is a program parameter) create and represent with histogram the distribution of P(t). Observe the behavior of the process for large n.

My Solution

Code in C#

In Disiegnagrafici

We graphicate the paths and the histograms as before but for sure now we use as a random step the new formula so i made a class WN graphicate ormalpaths and the histograms as before but for sure now we use as a random step the new formula so i made a class “NormalPathfinder” in witch i generate the list of value:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53


   public NormalPathfinder(int n, int m)
        {
            this.m = n;
            this.n = m;
            this.p = 0.5;

            this.R = new Random();

            for (int i=0; i < m; i++)
            {
                List<Double> list = createNormalList();
                paths.Add(new Strade(list));
                values.Add(list);
            }



        }

        private bool normal_Result(double p,out double ou)
        {
           double random_outcome =( R.NextDouble()+R.NextDouble());
            double normal_distrbAtOut;
            double v = R.NextDouble();
            //create a value between 1 and -1
            random_outcome = random_outcome  - 1;
            //get the standard normal for that point
            normal_distrbAtOut= Math.Pow(Math.E, (Math.Pow(-random_outcome, 2) / 2))/Math.Sqrt(2*Math.PI) ;
            //then use the other generated random
            if (v <= normal_distrbAtOut*Math.Sqrt(2*Math.PI))
            {
                ou = random_outcome;
                return true;
            }

            else { ou = 0; return false; }

        }

        private List<double> createNormalList()
        {
            List<double> normal = new List<double>();

            for (int i = 0; i < n; i++)
            {
                double j;
                if (normal_Result(p, out j))
                    normal.Add(j);
                else i--;
            }

            return normal;
        }

Here we use create also the path with a Strade object :

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16


     //Dalla lista di valori passo ai punti ;
        public Strade(List<double> values)
        {
            this.values = values;
            double sqrt1n = (double)1 / values.Count;
                Math.Sqrt(sqrt1n);
            double jump=0;

            for (int i=0; i < values.Count; i++)
            {

                    jump += (sqrt1n)*values[i];

                path.Add(new PointF(i + 1, (float) jump));
            }
        }
